Dell Vostro 1700 (Early 2009) - Manual (Page 166)

166
Adding and Replacing Parts
3 Replace the keyboard and hinge cover.
4 Insert the battery into the battery bay, or connect the AC adapter to your
computer and an electrical outlet.
5 Turn on the computer.
As the computer boots, it detects the additional memory and automatically
updates the system configuration information.
To confirm the amount of memory installed in the computer, click Start
→ Help and Support→ Dell System Information.
Removing the DIMM B Memory Module
The DIMM B memory module is located under the memory module/coin-cell
battery cover on the bottom of the computer.
1 Follow the procedures in "Before You Begin" on page 153.
2 Turn the computer upside-down, loosen the captive screw on the memory
module/coin-cell battery cover (see "Bottom View" on page 33), and
remove the cover.
1 tab 2 notch
1
2
