APPENDIX
APPENDIX
The numbers in parentheses indicate the pages where each part
is explained.
■
Camera
Front
Back
General Guide
1 Shutter (page 59)
2 Lens Cover (page 43)
3 Flash (page 72)
4 Lens
5 AF Assist/REC light/
Self-timer Lamp
(pages 58, 64, 77, 135, 272)
6 Microphone (pages 83, 99)
5
3 4 2 1
6
7 Monitor Screen (page 53)
8 Zoom controller
(pages 69, 169, 170)
9 Operation Lamp
(pages 43, 59, 272)
bk Mode dial (page 56)
bl Strap Hole (page 2)
bm Control Button
([ S], [T], [W], [X])
bn [SET] Button
bo [MENU] Button (page 51)
bp [ ] (PLAY) Button
(pages 43, 217)
bp
8 9 7 bk bl
bm bo bn
[ S]
[ W]
[ T]
[ X]
[SET]
