Caution – Char-Broil 463666512 User Manual
Page 21
9
10
21
Place vaporiser bar onto V-shaped bar rest inside firebox. Place cooking grate onto firebox.
Cooking Grate
Vaporiser Bar
Failure to install grease cup clip
and cup will cause hot grease to
drip from bottom of grill with risk
of fire or property damage.
CAUTION
Grease Cup and Grease Cup Clip
Hang grease cup clip from bottom of firebox, and place grease cup into grease cup clip.
Grease Cup
Grease Cup Clip
