Fail-Safe • Customer First Center • 1121 Highway 74 South • Peachtree City, GA 30269 • TEL 770.486.4800 • FAX 770.486.4801
04/17/2007 3:31:05 PM
Specifications and Dimensions subject to change without notice.
ADC041534
PHOTOMETRICS
ORDERING INFORMATION
SHIPPING INFORMATION
FRS-2
Zone Lumens %Lamp %Fixture
0- 30
1159
20.3
28.4
0- 40
1904
33.4
46.6
0- 60
3131
54.9
76.7
0- 90
3882
68.1
95.1
90-180
199
3.5
4.9
0-180
4081
71.6
100.0
0
1
2
3
4
5
6
7
8
9
10
FRS-232-120
(2) F32T8/735/RS Lamps
2850 Lumens each
Efficiency: 72%
Plane:
0
o
90
o
Spacing Criteria: 1.2 1.3
Report # 8002.0
Zonal Lumen Summary
84 84 84 84 82 82 82 82 78 78 78 74 74 74 70 70 70 68
77 74 71 68 75 72 69 67 68 66 64 65 63 62 62 61 59 58
71 66 61 57 69 64 60 56 61 57 54 58 55 53 55 53 51 49
65 58 53 49 63 57 52 48 55 50 47 52 49 46 50 47 44 43
60 52 46 42 58 51 46 41 49 44 41 47 43 40 45 42 39 37
55 47 41 36 54 46 40 36 44 39 35 42 38 34 40 37 34 32
51 42 36 32 50 41 36 31 40 35 31 38 34 30 37 33 30 28
47 38 32 28 46 37 32 27 36 31 27 34 30 27 33 29 26 25
44 34 28 24 42 33 28 24 32 27 24 31 27 23 30 26 23 21
40 31 25 21 39 30 25 21 29 24 20 28 23 20 27 23 20 19
37 28 22 19 36 27 22 18 26 21 18 25 21 18 25 21 18 16
Angle
Along ||
45
o
Across
0
1449
1449
1449
10
1435
1439
1448
20
1375
1398
1411
30
1204
1241
1299
40
994
1069
1135
50
672
722
767
60
311
422
551
70
143
280
469
80
57
199
347
90
0
107
175
100
0
63
89
110
0
37
53
120
0
28
47
130
0
22
34
140
0
18
27
150
0
17
22
160
0
14
17
170
0
11
12
180
0
0
0
Candlepower
Coefficients of Utilization
Effective floor cavity reflectance 20%
rc 80% 70% 50% 30% 10% 0%
rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0
RCR
||
60
o
30
o
0
o
90
o
Catalog Number
Weight
FRS-217
11 lbs.
FRS-220
11 lbs.
FRS-232
19 lbs.
FRS-240
19 lbs.
FRS-240BX
11 lbs.
