Streetworks • Customer First Center • 1121 Highway 74 South • Peachtree City, GA 30269 • TEL 770.486.4800 • FAX 770.486.4801

08/04/2008 6:08:05 PM

Specifications and Dimensions subject to change without notice.

TLU_ADH081550

ORDERING INFORMATION

TALON LARGE

TLU

S A M P L E N U M B E R : T L 9 1 S W W 3 V F G

TLU

Product Family

1

TLU=Talon Site

Large

Lamp Wattage

25=250W

32=320W

2

35=350W

2

40=400W

75=750W

87=875W

2

91=1000W

3

Distribution

Horizontal Lamp

2F=Type II Formed

2S=Type II Segmented

4

3F=Type III Formed

3S=Type III Segmented

4

4F=Type IV Formed

4S=Type IV Segmented

4

5F=Type V Formed

5S=Type V Segmented

4

SL=Spill Light Eliminator

3

Vertical Lamp

3V=Type III Vertical

4V=Type IV Vertical

AR=Area Round

AS=Area Square

AF=Automotive Front Row

Lens Type

F=Flat Glass

S=Sag Glass

Options (add as suffix/must be

ordered in alphanumeric order)

1=Single Fuse

[120, 277 or 347V]

5

2=Double Fuse

[208, 240 or 480V]

5

3=Three Place Terminal Block

4=NEMA Twistlock

Photocontrol Receptacle

B=Internal House-side Shield

6

DM=Direct Mount for Pole

E=Quartz Restrike w/Delay

[Also Strikes at Cold Start]

7

H=Plug-in Starter Receptacle

8

HL=Hi/Low Dimming

9

L=Lamp Included

Q=Quartz Restrike

[Hot Restrike Only]

7

U=U.L. Listed

WM=Wall Bracket with

10 1/2" Arm

Accessories

(order separately/replace XX with color designation)

OA/RA1016=NEMA Photocontrol (105-285V)

OA/RA1027=NEMA Photocontrol (480V)

OA/RA1201=NEMA Photocontrol (347V)

OA/RA1013=Shorting Cap

MA1010-XX=Single Tenon Adapter for 3 1/2" O.D. Tenon

MA1011-XX=2 @ 180° Tenon Adapter for 3 1/2" O.D. Tenon

MA1012-XX=3 @ 120° Tenon Adapter for 3 1/2" O.D. Tenon

MA1013-XX=4 @ 90° Tenon Adapter for 3 1/2" O.D. Tenon

MA1014-XX=2 @ 90° Tenon Adapter for 3 1/2" O.D. Tenon

MA1015-XX=2 @ 120° Tenon Adapter for 3 1/2" O.D. Tenon

MA1016-XX=3 @ 90° Tenon Adapter for 3 1/2" O.D. Tenon

MA1017-XX=Single Tenon Adapter for 2 3/8" O.D. Tenon

MA1018-XX=2 @ 180° Tenon Adapter for 2 3/8" O.D. Tenon

MA1019-XX=3 @ 120° Tenon Adapter for 2 3/8" O.D. Tenon

MA1045-XX=4 @ 90° Tenon Adapter for 2 3/8" O.D. Tenon

MA1048-XX=2 @ 90° Tenon Adapter for 2 3/8" O.D. Tenon

MA1049-XX=3 @ 90° Tenon Adapter for 2 3/8" O.D. Tenon

MA1213-XX=External House-side Shield Kit [EPA=0.38]

6

NOTES: 1 10 1/2" arm and round pole adapter included with fixture. 2 320/350/875W Pulse Start Metal Halide lamp only. 3 Requires reduced envelope lamp. 4 Maximum wattage on segmented optical distributions is 400W.

400W Metal Halide lamp must use reduced envelope ED-28 lamp. 5 Must Specify Voltage. 6 House-side shield not available on 5S, 5F, AS, AR and SL optics. 7 Quartz options not available with SL and AF optics.
8 Not available in 1000W. 9 Requires vertical lamp orientation. Provides 24V low voltage leads used in dimming control. 10 Specifications and dimensions subject to change without notice.

Lamp Type

S=High Pressure Sodium

R=Super Metal Halide

M=Metal Halide

P=Pulse Start Metal Halide

Ballast Type

C=CWI

H=Reac./HPF

K=10KV CWA

M=Mag. Reg.

N=Hi. Reac./NPF

P=Hi. Reac./HPF

R=Reac./NPF

W=CWA

Colors (add as suffix/

must specify)

WH=White

BK=Black

AP=Grey

BZ=Bronze

DP=Dark Platinum

GM=Graphite Metallic

Voltage

2=120V

0=208V

4=240V

7=277V

8=480V

9=347V

N=Multi-Tap wired 277V

W=Multi-Tap wired 120V

V=Multi-Tap wired 240V
