TB731P/TB732P/TB733W
13 12
TB731P/TB732P/TB733W
Basic Operations
For your safety, the driver should not watch
the TV or operate the controls while driving.
Please note that watching and operating the
TV while driving is prohibited by law in
some countries. Also, while driving, keep
the volume to a level at which external
sounds can be heard.
Watching TV
1. Press the [BND] button to select TV1, TV2,
VTR1 or VTR2. Each time the [BND] button
is pressed, the setting is switched in the
sequence shown below.
CAUTION
TV Mode Operations
Auto store function
The channels received automatically are
automatically stored in the preset channels.
The setting procedure for the preset channels is
the same for TV1 and TV2.
1. Press the [PS] button for 1 second or longer,
the broadcast stations are automatically
stored in the memory starting with the one
following the station now received.
Seek tuning
Keep pressing the [ a] or [d] button for about
1 second.
The seek tuning mode is selected. Tuning will
stop automatically at a channel where a
broadcast is received.
∗ When seek tuning has stopped before or after a
broadcast channel, press the [ a] or [d] button
again.
Manual tuning
Press the [ a] or [d] button to select the
channel.
The channel number appears at the top right of
the screen.
∗ Each time the [a] or [d] button is pressed, the
channel number is incremented or decremented
by 1.
∗ The channel number remains on the screen for
about 5 seconds.
Preset memory function
The number of preset channels which can be
stored in the memory is:
• 6 stations for TV1
}
Total of 12 stations • 6 stations for TV2
Any station can be stored in any preset
channel.
TV1 TV2 VTR1 VTR2
A.STORE
F.WIDE
62
TV1
1
2
3
4
5
6
Selecting the screen size
Four screen display modes are supported:
normal, wide, full wide and cinema.
Note:
• The screen mode cannot be selected while the
vehicle is in motion.
Note:
• When the wide mode or full wide mode is used to
display a normal 4:3 picture which is not a wide
picture so that it fills the whole wide TV screen,
parts of the picture around the edges will be off
the screen or the picture will be distorted on the
screen. To view original pictures so as to respect
the intentions of the producer, use the normal
mode.
Press the [DISP] button for 1 second or longer to select the screen display mode. Each time this
button is pressed for 1 second or longer, the display mode is changed in the sequence shown below.
■ For normal 4:3 picture reception
Depending on which mode is set, the shape of the picture will be distorted on the screen.
■ For wide (16:9) picture reception
Use the cinema mode.
62
TV1
F.WIDE
62
TV1
CINEMA
62
TV1
WIDE
62
TV1
NORMAL
● Full wide mode
The whole picture is stretched
in the sideways direction.
● Cinema mode
The picture at the top and bottom
of the screen is off the screen.
● Wide mode
The picture at the left and right
of the screen is stretched in the
sideways direction.
In wide mode, the picture is
stretched in both the upward
and downward direction when a
PAL signal is received.
● Normal mode (normal screen)
Black bands appear to the left
and right of the screen.
● Normal mode ● Cinema mode
Wide mode,
full wide
Black bands appear all around the
screen. The picture is shown expanded
so that it fills the whole screen.
62
TV1
CINEMA
62
TV1
NORMAL
Notes:
• The signal conditions are sometimes such that a
channel without a station is stored in the memory.
• Some stations may not be stored if their signals
are too weak in the reception area.
• When a station could not be stored or a channel
without a station has been stored in the memory,
refer to the section on the manual memory
function which follows, and perform the settings
again.
Manual memory function
1. Press the [BND] button to select TV1 or
TV2.
2. Press the [MEMO] button, the manual
memory screen is displayed.
∗ While the channel display at the left of the
screen turns red, the manual memory
operation is available.
3. Press the [ a] ro [d] button to select the
channel to be preset.
4. Press the [ w] or [z] button to select the
preset channel in which the station to be
stored.
5. Press the [MEMO] button for 1 second or
longer to store the station into the preset
memory.
6. To cancel the manual memory mode, press
the [MEMO] button again and press the
[DISP] button.
Note:
• The memory contents are returned to the default
settings when the battery is replaced or the
power supply is otherwise suspended.
