Clarion TB733W - Manual (Page 2)

2
TB731P/TB732P/TB733W TB731P/TB732P/TB733W
81
English
Owner
’s
manual
Thank you for purchasing the Clarion TB731P/TB732P/TB733W.
* Please read this Owner’s manual & Installation manual in its entirety before proceeding with wire
connection and installation.
* After reading this manual, be sure to keep it in a handy place (e.g., glove compartment).
■ Contents
•
Owner’s manual
1. FEATURES ........................................................................................................................................ 3
2. PRECAUTIONS ................................................................................................................................. 4
3. CONTROLS ....................................................................................................................................... 5
4. BUTTON TERMINOLOGY ................................................................................................................ 6
5. CAUTIONS ON HANDLING .............................................................................................................. 7
Concerning the LCD screen ............................................................................................................... 7
Cleaning ............................................................................................................................................. 7
Concerning the wide screen .............................................................................................................. 7
6. REMOTE CONTROL ......................................................................................................................... 8
7. OPERATION .................................................................................................................................... 10
Basic Operations .............................................................................................................................. 10
TV Mode Operations ........................................................................................................................ 13
8. TROUBLESHOOTING .................................................................................................................... 17
9. SPECIFICATIONS ........................................................................................................................... 19
• Installation and Wire connection manual
1. BEFORE STARTING ....................................................................................................................... 21
2. PACKAGE CONTENTS .................................................................................................................. 21
3. GENERAL CAUTIONS .................................................................................................................... 21
4. CAUTIONS ON INSTALLATION ..................................................................................................... 22
5. INSTALLING THE MAIN UNIT ........................................................................................................ 23
6. REMOVING THE MAIN UNIT .......................................................................................................... 25
7. CAUTIONS ON WIRING ................................................................................................................. 25
8. WIRE CONNECTIONS .................................................................................................................... 26
9. SAMPLE SYSTEMS ........................................................................................................................ 28
