Introduction
COLORado™ 2 Tour User Manual Rev. 02b -3-
2. Introduction
Product
Description
The COLORado™ 2 Tour is an RGBW wash light based on 48 LEDs. It consists of a
single pod with a double bracket mounting yoke. The AC power comes directly into
the fixture’s housing through a NEUTRIK® powerCON A socket. The power linking
uses a NEUTRIK® powerCON B socket. The DMX input and output sockets are of the
3-pin XLR type. The COLORado™ 2 Tour uses a display-based control panel for
programming functions.
Features • 3, 4, 5, 6, or 11-channel DMX, RGBW
• LED wash light (with ID addressing)
• Operating modes (personalities)
3-channel: RGB control
3-channel: HSV control (hue, saturation, and value)
4-channel: RGBW control
4-channel: RGB, dimmer
5-channel: RGBW, dimmer
6-channel: RGBW, dimmer, strobe
11-channel: RGBW, ID, dimmer, strobe, macro, auto/custom, dimmer speed,
auto speed
• RGBW color mixing with or without DMX controller
• Color temperature presets (3,200~10,000 K)
• Built-in automated programs via DMX
• Recall custom programs via DMX
Additional Features • High-power, 2~3 W (750~1,000 mA) LEDs
• Additional power output: max
5 units @ 120 V
• Adjustable barn doors to direct output (includes gel frame)
• LED display with lock-out feature
• NEUTRIK® powerCON connector
• 3-pin DMX input and output connectors
Options • Top hat (C2TOP)
• Optical systems: 15° (installed), 30° (CLENS3048)
