iDP-3540/41 User’s Manual
CITIZEN 38/48
Bit image mode printing is performed by this command. (n2 is the equotient when divided by 256,
and n1 is the remainder.) When data is received only for numbers specified by n1 and n2, printing
and line feed are carried out automatically, and the bit image mode is cancelled.
However, since “half-dots” are being used, the next corresponding pin cannot print at the same
time.
Further, the maximum value of n1 and n2 is the number contained in one line, and this cannot be
exceeded.
Relation of Head Pins to Data
12-2-13. 1/9 inch Line Feed Pitch Set Command (Graphic Type)
1
st
byte
D8 D1
0 0 0 1 1 0 1 1
ESC (1B) H
2
nd
byte
D8 D1
0 0 1 1 0 0 0 1
1(31)H
12-2-14. 2/9 inch Line Feed Set Command (Graphic Type)
1
st
byte
D8 D1
0 0 0 1 1 0 1 1
ESC (1B) H
2
nd
byte
D8 D1
0 0 0 1 0 0 0 1
2(32)H
