iDP-3540/41 User’s Manual
CITIZEN 31/48
11. Function Selection
In order to meet the widest possible range of needs, various conditions can be selected by setting
the DIP switches.
11-1. Setting DIP Switch DS1
No. Function OFF ON Factory
Setting
1 Auto Cutter NO YES *1
2 International country (Refer to table below) OFF
3 switching OFF
4 Input buffer 7K Bytes 2 Lines OFF
5 Character direction Normal Inverted OFF
6 CR cord CR CR + LF OFF
7 Mode Character Graphic *1
8 SEL / DESEL at "power on " SELECT DESELECT OFF
Notes: *1) Setting is variable, depending on the type of printer.
No. USA FRANCE GERMAN
Y
ENGLAND
2 OFF ON OFF ON
3 OFF OFF ON ON
11-2. Setting DIP Switch DS2
1) Serial interface only
No. Function OFF ON Factory
Setting
1 Word length setting 8 bits 7 bits OFF
2 Parity check YES NO ON
3 Parity condition ODD EVEN OFF
4 - Not used -
5 OFF
6 Baud rate setting (Refer to the table
below) ON
7 ON
8 OFF
