iDP-3540/41 User’s Manual
CITIZEN 35/48
12-2-4. Paper feed command
D8 D1
0 0 0 0 1 0 1 0
LF(0A)H
When there is data in the internal print buffer, line feed will be carried out after printing is
completed. When the buffer is empty, line feed only will be carried out.
12-2-5. Print command
D8 D1
0 0 0 0 1 1 0 1
CR(0D)H
By means of this command, printing will be carried out. In order to accommodate the print data
output formats of various computers, the CR function is selectable.
(Please refer to 11-1 DIP Switch Setting)
12-2-6. Clear command
D8 D1
0 0 0 1 1 0 0 0
CAN(18)H
Print data previously entered on the same line can be cleared by the command.
12-2-7. Red color print command
D8 D1
0 0 0 1 0 0 1 0
DC3(13)H
This command specifies red colored characters and all of the characters on one line will be printed
in red. Since this command is cancelled after printing one line, it is necessary to use it for each line
on which red printing is desired.
