Setting Up Your Wireless AP Router 3-2
3. Set up your Wireless AP Router as shown in Figure 3-2.
Up to four computers can
be connected via wire to
your Wireless AP Router.
Figure 3-2
Wireless clients
Wireless AP Router
Power
adapter
RJ-45
Ethernet
cable
Ethernet port
DSL modem
or cable
modem
Power outlet
Wired client
(optional)
Wall
outlet
Ethernet port
