PA201
www.baumer.com 19
Technical data - mechanical design
Ambient temperature
-10...+60 °C
Storing temperature -25...+85 °C
Relative humidity 95 % non-condensing
Connection Spring-loaded terminal connector,
detachable
Core cross-section 1 mm² (Grid 2.54)
2.5 mm 2 (Grid 7.62)
Protection DIN EN 60529 IP 65 (face)
Operation / keypad 3 softkeys below bezel
Housing type Built-in housing
Dimensions W x H x L 48 x 24 x 106 mm
Mounting Front panel installation by clip frame
Material Housing: Polycarbonate, UL 94V-0
Weight approx. 50 g
5.1 Dimensions
PA201 - without clip frame
PA201 - clip frame mounting
6 Part number
PA201.00 AX01
Voltage supply
4 85...265 VAC and 100...300 VDC
5 21...53 VAC and 10.5...70 VDC
