Easy programming via handheld tool.
Convenient programming via PC software.
The convenient PC software is ideal for distributors or drive manufacturers who need
to program several encoders in line. Simply select the desired configuration profile and just a
mouseclick later it’s all done:
Thanks to a compact handheld programming tool, encoder configuration is done in se-
conds – even if the encoder is already integrated in the system. Handling the battery-operated
stand-alone solution is child’s play:
„ „ Four user-assigned buttons for simple and
quick programming
„ „
Memory of several encoder configuration profiles
„ „
Intuitive, fully menu-driven programming
„ „
Backlit display
„ „
Good readability under any ambient light condition
„ „ Encoder diagnostics
„ „ LED activity indicator
Our software library provides decisive benefits:
Enhanced efficiency through automated product
documentation and improved traceability:
Integration with your ERP system automatically defines
all parameters in the production process and will
allocate serial number and pertinent encoder
configuration directly to the related production order. Eliminating downtime:
Implemeted in the control or HMI software,
the encoder configuration is updated directly in
the process without manual intervention and
production
loss.
„ „
Efficient programming by automatic identification
of the connected devices
„ „ Easy, intuitive operation and programming
„ „
Quick and efficient configuration by user-assigned buttons
„ „
Encoder diagnostics with on-screen readout
„ „
On-screen feedback of the programming process
„ „
Perfect product documentation by individual
product label print outs
