DWZZH 16–Bit UltraSCSI Hub (Rack-Mountable)
viii EK–SMDZS–UG. B01
Shared Storage Solutions Using UltraSCSI Hubs EK-SMA21-AN
Shared Storage for Windows NT Using UltraSCSI Hubs EK-SMA17-AN
Shared Storage for OpenVMS Using UltraSCSI Hubs EK-SMA19-AN
Shared Storage for DIGITAL UNIX Using UltraSCSI Hubs EK-SMA20-AN
Shared Storage for Sun Solaris Using UltraSCSI Hubs EK-SMA18-AN
Document Structure
This guide contains the following chapters:
Chapter 1. Introducing the 16-Bit UltraSCSI Hub (Rack-Mountable)
This chapter gives brief functional and physical descriptions of the DWZZH Hub
and lists significant product specifications.
Chapter 2. Setting Up the DWZZH-09
This chapter gives instructions for installing the 0.5m cable on the DWZZH-09
Hub.
Chapter 3. Using the 16-Bit UltraSCSI Hub
This chapter gives procedures for configuring a StorageWorks SCSI bus using a
DWZZH Hub.
Chapter 4. Installing the DWZZH-09 Upgrade Kit
This chapter gives instructions for installing the DWZZH-09 Upgrade Kit in a
DWZZH-S5.
Chapter 5. SWCC and UltraSCSI Hubs
This chapter is intended to provide you with some important information
regarding the use of StorageWorks Command Console (SWCC) on SCSI buses
that have an UltraSCSI Hub. While the information provided here is important,
it is essential that you have read the SWCC manual and release notes.
Appendix A. Removable Parts of the DWZZH-S5 and DWZZH-09
This Appendix identifies the parts that can be removed and replaced from the
DWZZH-S5/-09 16-Bit UltraSCSI Rack-Mountable Hubs.
Glossary
The Glossary defines terms that are used frequently with StorageWorks and SCSI
bus components.
