Protected components Fuse amp rating Fuse or relay number
Electronic power assist steering module 15 5A* F26
Mass air flow sensor 5A* F27
Powertrain control module 15A* F28
Electronic air conditioning compressor /
Positive temperature coefficient heater 10A* F29
Engine control module, Powertrain control
module 10A* F30
Charge port light ring (C-MAX Energi) 5A* F31
Vehicle power 2 20A* F32
Vehicle power 4 15A* F33
Injectors 10A* F34
Vehicle power 3 10A* F35
Vehicle power 1 20A* F36
Not used — R1
Horn Micro relay R2
Hybrid powertrain control Micro relay R3
Front wiper Micro relay R4
Not used — R5
Front and rear wiper high/low Micro relay R6
Vacuum pump Power relay R7
Ignition feed Power relay R8
Not used — R9
Vacuum pump sensor Mini relay R10
Not used — R11
Cooling fan Power relay R12
Heater blower Mini relay R13
Engine control relay Mini relay R14
*Mini fuses **Cartridge fuses
