Char-Broil 463420509 User Manual
Page 18
Rear
4
3
Attach front brace to cart frames using two #10-24x1/2
” screws, 5mm lock washers and 5mm flat washers on each side.
Magnet
#10-24x1/2" screws
5mm flat washers
5mm lock washers
Attach rear cart brace to cart frames using two #10-24x1/2
” screws, 5mm lock washers and 5mm flat washers on each side.
18
