Humboldt HM-1327 Humboldt Marshall/TSR Loader User Manual
Page 23

20
* RECALL CALIBRATION
* CHANGE DEVICE ID
Press
(CHANGE DEVICE ID). You should see this screen:
Press
to increase the ID number or press
to decrease the
number. Once the ID has been changed, press
to go back to previous
menu. Note: Up to 16 devices can be connected to a single computer.
SENSOR LIMITS
Sensor upper limits can be set to ON or OFF. If the Sensor’s Upper
limit is set to ON and the motor/test is in progress, when the sensor
reaches its upper limit, the motor/test will stop and a warning message
will be displayed. In addition, if a sensor has been unplugged from the
instrumentation back panel, the same warning message will be displayed.
RAW_DATA
RAW-DATA refers to the digital output of the sensors prior to apply the
calibration factor and conversion into engineering units.
DEVICE ID = 1
* INCREASE
* DECREASE
