Sensor Min
The Sensor Zero (SENSOR MIN) is not configurable and is set at 0.
Sensor Max
Press
(SENSOR MAX) to set the Sensor Maximum value.
You should see this screen:
16
“CH1” MAX SETUP
* SENSOR MAX =
“000000”
* INCREASE
* DECREASE
Press (SENSOR MAX) to move between the numbers. Keep pressing
until the digit you want to change is flashing. Once you have
selected the number you want to change, press (INCREASE) or
(DECREASE) to change the number to the desired value. Below is a
configuration chart for Humboldt instrumentation. These are the numbers
that correspond to each Humboldt sensors.
Load Cell Part# English Max (lbf) Metric Max (kN)
10,000 lb. (50kN) HM-2300.100 010000 050.00
5,000 lb. (25kN) HM-2300.050 005000 025.00
2,000 lb. (10kN) HM-2300.020 2000.0 10.000
1,000 lb. (5kN) HM-2300.010 1000.0 05.000
500 lb. (2.5kN) HM-2300.005 0500.0 02.500
LVDT Transducer Part# English Max (in.) Metric Max (mm)
0.4" (10.0mm) HM-2310.04 0.4000 10.000
1.0" (25.4mm) HM-2310.10 01.000 25.000
2.0" (50.8mm) HM-2310.20 02.000 50.000
Pore Pressure Part# English Max (psi) Metric Max (kPa)
100psi (1000kPa) HM-2300.100 0100.0 001000
To return to any prior screen you can always press
