Attaching the Soundbar(Optional)

Back to Contents Page

1

Working from the rear of the monitor, attach Soundbar by aligning the two slots with the two tabs along the bottom rear of the monitor.

2

Slide the Soundbar to the left until it snaps into place.

3

Connect the Soundbar with the DC power connector.

4

Insert the mini stereo plug from the rear of the Soundbar into the computer's audio output jack.

CAUTION:

Do not use with any device other than Dell Soundbar

NOTE:

Monitor DC power connector +12 V DC output is for Dell Soundbar, that does not have built-in AC adapter, eg Dell AX510.
