HDMI Connector
Pin
Number 19-pin Side of the Connected Signal
Cable
1 TMDS DATA 2+
2 TMDS DATA 2 SHIELD
3 TMDS DATA 2-
4 TMDS DATA 1+
5 TMDS DATA 1 SHIELD
6 TMDS DATA 1-
7 TMDS DATA 0+
8 TMDS DATA 0 SHIELD
9 TMDS DATA 0-
10 TMDS CLOCK
11 TMDS CLOCK SHIELD
12 TMDS CLOCK-
13 Floating
14 Floating
15 DDC CLOCK (SDA)
16 DDC DATA (SDA)
17 GROUND
18 +5V POWER
19 HOT PLUG DETECT
Flat Panel Specifications
Screen type Active matrix - TFT LCD
Panel type IPS
Screen dimensions 24 inches (24-inch diagonal viewable image size)
Preset display area:
Horizontal
518.4mm (20.41 inches)
Vertical
324.0mm (12.75 inches)
Pixel pitch 0.27mmx0.27mm
Viewing angle 178° (Vertical) typical, 178° (Horizontal) typical
Luminance output 400 cd/m ²(typ)
Contrast ratio 1000:1 (typ), 80,000:1 (Max, Dynamic Contrast on)
Faceplate coating Antiglare with hard-coating 3H
Backlight 7 CCFL U-type system
Response Time 6ms panel typical (Grey to Grey)
Color Gamut 110 % (typ.)
