Operating the Monitor
Dell™ U2410 Flat Panel Monitor User's Guide
Using the Front Panel Controls
Using the On-Screen Display (OSD) Menu
Setting the Maximum Resolution
Using the Dell Soundbar (Optional)
Using the Tilt, Swivel and Vertical Extension
Rotating the monitor
Adjusting the Rotation Display Settings of Your System
Using the Front Panel
Use the buttons on the front of the monitor to adjust the image settings. 1~5 are capacitive touch sensor keys, activated by placing the finger on the Blue LED
button.
1-3 Shortcut keys Use this key for direct access to the control menu that you define in the personalize menu.
For example, use the second shortcut key to activate Brightness/Contrast adjustment.
*The default settings are Preset Modes Select, Brightness/Contrast Select and Input Source Select.
1
Preset Modes Select
Use this button to select different image modes on your monitor.
2
Brightness/Contrast
Use this button for direct access to the "Brightness/Contrast" control menu.
3
Input Source Select
Use Input Source Select button to select between different video signals that may be connected to your monitor.
l VGA input
l DVI-D 1 input
l DVI-D 2 input
l DisplayPort input
