1
2
1 display assembly 2 screws (4)
Replacing the Display Assembly
1 Follow the instructions in "Before You Begin" on page 9.
2 Place the display assembly in position and replace the four screws (two on
each side) that secure the display assembly to the computer base.
3 Route the display cable and Mini-Card antenna cables through the routing
guides.
4 Connect the Mini-Card antenna cables to the Mini-Card. See "Replacing
the Mini-Card" on page 27.
5 Connect the display cable to the connector on the system board.
6 Replace the hinge cover. See "Replacing the Hinge Cover" on page 53.
7 Follow the instructions from step 3 to step 7 in "Replacing the Palm-Rest
Assembly" on page 32.
Display 58
