REV B 10/18/12, ECN 8972
6
Figure 5: Step 5 Figure 6: Step 6
7 Starting the VibraScout ™ application
The 7543A Accelerometer must be connected to a USB port prior to starting the VibraScout™
application or the application will not function. After connecting the 7543A to a USB port, the
device enumerates as an external storage device with 5 KB of available file storage. The drive
space can store up to three VibraScout™ parameter files or other customer files. The on‐screen
enumeration window is the first indication that the USB communication between the 7543A
and the host PC is functioning properly. The enumeration window may be closed prior to
running the VibraScout™ application.
Figure 7: Enumeration window.
