REV B 10/18/12, ECN 8972
15
 Reproduce interpolated oversampled data to provide better resolution of vibration
signals
 Multiple file types to export to including: ASCII, time history.JPG files, TDMS
binary files of time history data readable in Microsoft Excel, PSD and FFT plots in
Joint Photographic file format.
 Display of recorded average temperature
11 Minimum System Requirements
Personal Computer running Windows XP/Vista/7 x86 or Windows XP/Vista/7 x64 with at least
2GB RAM or higher. 163MB of free hard disk space is required.
12 Installation
Please contact Dytran Instruments, Inc. at (818) 700‐7818 for latest software revision. Check software
revision while installing on welcome screen as in Figure 18.
To Install from CD:
Insert CD into an empty CD/DVD ROM drive. Navigate to My Computer>CD/DVD ROM
Drive>VibraScout PP folder and double click on setup.exe. This will start the installer. Follow the
step by step prompts to completely install the Post Processor software.
Leave all file paths in their default directories.
Note: Please make sure all windows applications are saved and closed before starting
installation as system will ask to restart for the first time of installation.
After installation is completed, Installer will create a shortcut on the Desktop and in the Start
Menu programs under Dytran>VibraScoutPP folder.
