TSFM 500 DC 10 32-1101 REV 2 710
5.9 Baud Rate (BAUD RATE)
This setting corresponds to the baud rate setting of the computer program controlling the test stand.
Default setting: 19200
Available settings:
1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200
5.10 Stop Bits and Parity (STOP & PAR)
This setting corresponds to the stop bits and parity settings of the computer program controlling the test stand.
Default setting: 8-1n
Available settings:
8-1E 8 stop bits, 1 stop bit, even parity
8-1o 8 stop bits, 1 stop bit, odd parity
8-1n 8 data bits, 1 stop bit, no parity
8-2n 8 data bits, 2 stop bits, no parity
7-1E 7 data bits, 1 stop bit, even parity
7-1o 7 data bits, 1 stop bit, odd parity
7-2E 7 data bits, 2 stop bits, even parity
7-2o 7 data bits, 2 stop bits, odd parity
7-2n 7 data bits, 2 stop bits, no parity
