CF 150 LTL 730 7 12/08
Peak force and unit of measure on 2nd line
104.5 lbf
302.5 lbf
Format #3
Live force value plus unit of measure on 1st line
Peak force and unit of measure on 2nd line
Descriptive prefixes on each line
Force 104.5 lbf
Peak 302.5 lbf
Format #4
Fixed position output. Works well with RS-232 utilities, such as WedgeLink, for parsing into a
spreadsheet such as Microsoft Excel. (comma- separated).
Excel A B
1 104.5 lbf
2 302.5 lbf
Fixed characters.
Position Description
1-8
Live force number
10-16 Displayed unit of measure (up to 7 characters)
18-25 Peak force number
27-33 Displayed unit of measure (up to 7 characters)
9, 17, 26 Commas
34 Carriage return
Example 1
104.5,lbf, 302.5,lbf
Example 2 (custom unit)
140000.,kg,165450., ,kg
This would yield (shown in courier):
111111111122222222223333333333444444444455555555
123456789012345678901234567890123456789012345678901234567
104.5, lbf, 302.5, lbf,
140000., kg, 165450., kg,
Format #5
Live force, unit of measure, peak force, unit of measure. All tab separated.
104.5lbf (if presently displaying live readings)
302.5lbf (if presently displaying peak readings)
104.5lbf302.5lbf (if presently displaying dual mode)
Setup Misc
Press the Misc key to access the following soft key set (refer to Figure 4):
Flash
Press this soft key to enable or disable the “display flash” feedback. If enabled, the press of a key
causes the display to momentarily flash to give you a visual feedback that the key was activated.
Zero Press this soft key enable or disable if a press of the Zero key also clears the Peak force value. If you
enable this function, press the Zero key to clear the Peak force and zero the load. If you disable the
function, the Zero key will only zero the load. Peak force remains in effect and will only be cleared
with the Clear function during operation.
