Page 3

iii.

to the

System

and press the

Program

hardkey.

iv.

Select

List of Methods.

Select your Method of interest and open it using the

Open

softkey.

Press the

Program

hardkey again (the key light will remain on).

vi.

Press the

Export

softkey to send the Method to Data View.

vii. The Method may now be viewed in Data View by clicking the

Method

button. Click the

Print button access

print dialog box where you can choose to print just the Method.

After a Method has been run, the

System automatically sends the list of Method steps to the

Data View

application where it may be viewed by clicking on the

Method

button.

To Monitor a Run

If necessary, click the

Clear

button or the

Chart Recorder

tab to obtain a blank chart recorder screen.

When a Method is started from the

System,

Data View will start automatically and will record all W

and conductivity data as well as event marks such as fraction collection events.

Start, Hold, Continue,

and

Pause events

are automatically recorded.

To Save a Run

At the end of a Run, click on the

Save

button. You will be asked to name the Run. Runs are saved as

Data Files.

Data View will automatically ask if you wish to save a Run if you try to clear the chart recorder screen or exit the

application without a prior Save.

To Add Notes a Run

Click on the

Notes

button.

To View The Method After The Run is Finished

Click on the

Method

button.

To Print The Run

Method and Notes

Open the Run of interest and

axes as desired. Click on the

Print

button. A dialog box will ask you to select what

Run parameters are printed.

Exporting Data to a Spreadsheet Program

Open the run of interest and

the time axis as required.

From the

File

menu select

Export Data.

A dialog box will ask you to select what run parameters should be exported as a

text file. This text tile may then be opened in a spreadsheet program such as Microsoft@ Excel.

Section 3 Using Data View with the Data Logging function

Data View includes a Data Logging feature which can be turned on and off using the Log On/Log Off buttons. The

advantage of using this feature is that, in the event of a power failure during a Run, the temporary hidden file is not
deleted and the Run data may be recovered.

With Log

selected, all data sent from the

System is automatically stored to the computer hard drive in a

temporary hidden tile. Data is stored even if the

Data View application is not active as a chart recorder.

Log Data may be saved as a discrete Log File using the

Save Log

command under the

File

menu. A

Log File may

opened using

Open Log

under the

File

menu. User-selected parts of a file may then be viewed,

and stored using

the

Save selected data

as command under the

File

menu. The selected data is then stored as a Data File and may be viewed

by clicking the

Open

button.

If the Log File is not saved by the user, then the temporary hidden file is deleted whenever the

Data View application

is exited. This prevents the hard drive of your computer from being filled with unnecessary data.

See the HELP feature for a more detailed description of Data Logging.
