11
WARNING
• ALMOST ALL WELD CRACKS OR FATIGUE FAILURES ARE
CAUSED BY IMpROpER INSTALLATION AND ARE NOT COVERED
BY WARRANTY.
WARNING
• REGULATIONS REQUIRE ThAT ALL WIRING BE DONE BY A
LICENSED ELECTRICIAN, FAILURE TO DO SO COULD VOID
YOUR WARRANTY.
NOTICE
• Any warranty claims for electrical components can only be considered
when submitted with proof of proper electrical installation.
installation
&
operation
proper care, maintenance and lubrication ensures longevity. The
compressor should always be level for proper lubrication. Use only in a
clean, dry, and well-ventilated area. The compressor has heat dissipation
fins for proper cooling. Keep the fins and other parts that collect dust
clean. Do not place rags or other materials on top of the compressor, as
this obstructs cooling and can be a fire hazard.
Mount the compressor on a concrete pad or solid floor, making certain
that the air receiver feet are level and that no stress is placed on the legs
when the mounting nuts, if used, are tightened, shim feet if necessary.
Severe vibrations will result when feet are uneven and drawn tightly to
the floor, which can lead to welds cracking or fatigue failure of the air
receiver.
A) Single phase models with factory installed wiring between the electric
motor and the pressure switch, - do not require a magnetic starter.
B) Single phase models which are not pre wired between pressure
switch and motor require a magnetic starter or combo switch.
C) Three phase models require magnetic starters or combi-pressure
switches and are not factory pre-wired in any way.
MOUNTING
WIRING
Installation & Operation
INSTALLATION
