Baseline Wi-Fi Module Configuration Guide
2
Step 1 – Get Network Info
When you use a Baseline Wi-Fi module to connect BaseStation 3200 V12 controller to an existing
wireless network, you need to configure the Wi-Fi module with information specific to that
network.
Ask the network administrator at the site for the following information:
Network Name (SSID): _____________________________________________________
Wi-Fi Key or Passcode: _____________________________________________________
Carefully record the Wi-Fi Key or Passcode noting the case of all letters and clearly distinguishing
ones and zeroes from similar alpha characters.
Step 2 – Configure the Computer to Connect to the Wi-Fi
Module
You need a Microsoft Windows-based computer or a Macintosh computer to configure the Wi-Fi
module. You configure the computer to use a static IP address, and then the computer will be able
to connect to the Wi-Fi module.
Microsoft Windows
1. To navigate to the Local Area Connection Properties dialog box, use the instructions for the
version of Windows operating system that is running on your computer. After you have
navigated to the dialog box, continue with Step 2:
XP: Click the Start Menu/Windows Logo > Control Panel Select > Network Connections (if
unavailable, select show Classic view). Select Network Connections, right-click Local Area
Connection, and then click Properties.
Vista: Click the Start Menu/Windows Logo > Control Panel > Network and Sharing Center >
Manage Network Connections. Right-click Local Area Connection, and then click Properties.
Windows 7: Click the Start Menu/Windows Logo > Control Panel (View by needs to be set to
Categories) > View Network Status and Tasks > Change Adapter Settings. Right-click Local
Area Connection, and then click Properties.
Windows 8: Press the Windows key on your keyboard. The Windows 8 Start Screen opens. In
the Search field, type control panel, and then press Enter. Click on View Network Status and
Tasks > Change Adapter Settings. Right-click Local Area Connection, and then click Properties.
