Specifications
Model 141 142 144
Max Input 0dBfs +24dBu 0dBfs
Max Output +24dBu 0dBfs 0dBfs
THD+Noise -100dB -100dB N/A
Dynamic Range 114dB 114dB N/A
Trim Range 12dB 12dB N/A
Jitter <1nsec <1nsec <1nsec
Power Consumption 10 Watts
Frequency Response 20Hz 20kHz ±0.5dB N/A
Size 1RU 1/2 Rack Width 1.75”H x 8.25”W x 7.25”D
Weight 3.5lbs (1.6kg) (44.5mm x 209.5mm x 184.2mm)
Connectors Toslink Toslink Toslink (2)
25 Pin D-sub Tascam Format 25 Pin D-sub Tascam Format 15 Pin D-sub Aphex Format (2)
BNC Word Clock
COPYRIGHT 2008 by Aphex Systems, LTD . All rights reserved . All Aphex products are trademarks or registered trademarks of Aphex Systems , LTD .
Other brand and product names are Trademarks of their respective holders.
3.0 specification
Model 141 ADAT to Analog Converter
Model 142 Analog to ADAT Converter
Model 144 AES/ADAT Bi-directional Converter
All specifications are subject to change without notice.
