Aphex 320D Compellor - Manual (Page 15)

320D
Compellor
Page 14 Page 15
5.6 RATIO
Compressor:
1.1:1 to 3:1 program dependent
Leveler: 20:1
Limiter: >30:1
5.7 ATTACK TIMES
Compressor:
5 to 50mSec program dependent
Leveler, fast: 20Hz = 1.5 Sec > 1KHz Frequency Discriminate Leveler
Leveler, slow: 20Hz = 5 Sec > 1KHz Frequency Discriminate Leveler
Limiter: 1 uSec
5.8 RELEASE TIMES
Compressor:
200 mSec to 1 Sec program dependent
Leveler, fast: 3 Sec
Leveler, slow: 10 Sec
Limiter: 200 mSec
5.9 DIGITAL AUDIO
Input SR:
Locks to 44.1, 48, 88.2, 96kHz +/- 3%
I/O Type: AES/EBU 110 ohms XLR
Default Output SR: User definable by replacing crystal; 48kHz standard
Word Clock: Not Supported
5.10 OTHER SPECIFICATIONS
AC input:
IEC standard receptacle with voltage selector, fuse, & filter
Power requirements: 100-120-220-240VAC, 50-60Hz
Power input (max): 20 watts
Dimensions: 19”W x 1.75” H x 10.125” overall depth
depth behind front panel = 9.25”
Net weight: 8 lbs.
Shipping weight: 9 lbs.
