Page 9

Approval Signature
Date
Phone No.
DETAIL A
4.773”
[121.23mm]
2 5/8”
[66.68mm]
10 - 32
TAPPED HOLE
5 x O .250”
3/4”
[19.05mm]
3/4”
[19.05mm]
3/4”
[19.05mm]
1 1/2”
[38.1mm]
2 9/16”
[65.09mm]
4”
[101.6mm]
R 1/16” [1.59mm]
3/4”
[19.05mm]
4”
[101.6mm]
1 1/4”
[31.75mm]
5/8”
[15.88mm]
2 3/8”
[60.33mm]
1 3/16”
[30.16mm]
1 1/2”
[38.1mm]
1/4”
[6.35mm]
1 1/16”
[26.99mm]
5/8”
[15.88mm]
8x 0.171” [4.34mm]
2 EACH SIDE
6x 3/4” [19.05mm] KO, RECESSED
1 EACH SIDE, 2 IN BOTTOM
3/4”
[19.05mm]
11x 1/2” [12.7mm] KO, RECESSED
2 EACH SIDE, 3 IN BOTTOM
1/4”
[6.35mm]
7/64”
[2.769mm]
17/32”
[13.487mm]
1 1/8”
[28.575mm]
DETAIL A
8 - 32 UNC - 2B
TAPPED HOLE
1.47”
[0.058mm]
.188”
[4.78mm]
.673”
[17.09mm]
R 3/16” [17.09mm]
.246”
[6.25mm]
4.125”
[104.78mm]
.629”
[15.97mm]
.188” [ 4.78mm]
0
.394”
[10.02mm]
0
.331” [8.41mm]
.344” [ 8.74mm]
0
0
4 - R .344” [R 8.73mm]
4.125” [104.78mm]
.376” [9.55mm]
.409” [10.39mm]
.061” [1.55mm]
.203” [5.16mm]
Is a riser mounted termination box required? See diagram below
(refer to page 8 for locations).
Yes (Amico provides termination box - default)
No (Termination box will be supplied by others)
Termination Box
NOTE:
1.
Maximum of four, Termination Boxes can be mounted on a riser.
