Great Plains FH6800HD Predelivery Manual User Manual
Pre-delivery manual, Manufacturing, inc
Manufacturing, Inc.
© Copyright 2013
Printed 2014-01-14
564-070Q
EN
ORIGINAL INSTRUCTIONS
Pre-Delivery Manual
6000 Series Harrow
FH6424HD, FH6330HD, FH6336HD,
FH6642HD, FH6845HD, FH6848HD &
FH6851HD
Read the operator’s manual entirely. When you see this symbol, the
subsequent instructions and warnings are serious - follow without
exception. Your life and the lives of others depend on it!
Illustrations may show optional equipment not supplied with standard unit.
31686
