8/15/2006 401-226Q
13 Assembly
Refer to Figure 13
4. Engage the lower latch.
5. Re-engage the drive coupler. It will automati-
cally snap back into engagement when plant-
ing begins.
Refer to Figure 14
6. Place seed hose over the meter opening and
slide retaining ring down to secure in place.
7. Before starting to plant, fill meters by running
the fan while stationary.
Seed Meter Wheel Installation
Choose the correct seed meter wheel for the type
of seed you will be using. Be sure to use the same
wheel type on all meters.
Important: Seed meter wheels for the inter-
changeable meter 25 series row unit are made
of a green color material and are not inter-
changeable with the other Great Plains seed
meter wheels for other machines. Use only
green wheels in interchangeable meter 25 se-
ries row units.
Refer to Figure 15
1. Push in spring-loaded wheel retainer and
turn. Pull off wheel retainer and spring.
Refer to Figure 16
2. Remove seed meter wheel.
3. Place new wheel on meter shaft and replace
spring-loaded wheel retainer.
21921
22883
Figure 13
22911
Figure 15
22913
Figure 14
Figure 16
