Great Plains Simba Culti Press 2009 Parts Manual - Manual (Page 91)

127 CultiPress
Operating Instructions
7. Parts & Assembly
AS0624 CU LT IPR ESS 2004
W OB LEVEL BOAR D H YD R AU LICS
IT EM PART NO DESCRIPT ION QT Y COMMENT S
1 P00205 QRC 1/2" BSP MALE 2
2 P02263 DOWTY SEAL 1/2" BSP 2
3 P00203 M-M1/2" 2
4 P09343 HA 3/8"x2135 - 1/2" 2
5 P09316 BULKHEAD 3/8" 4
6 P12687 HA 3/8"x3420 90° 2
7
8
9
P09346 HA 3/8"x1220 2
10 P09318 T 3/8" MALE 2
11 P09314 M-M3/8" 4
12 P03687 DOWTY SEAL 3/8" 4
13 P09347 HA 3/8"x650 90° 1
14 P09324 HA 3/8"x830 90° 1
15 P09329 HA 3/8"x1650 90° 1
16 P09323 HA 3/8"x190 90° 1
17 P08013 CYL - Ø63x130 2
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
