55 CultiPress
Operating Instructions
7. Parts & Assembly
AS1797 CU LT IPR ESS 2005
4.0m W OB ASSEMBLY PR OACT IVE
IT EM PART NO DESCRIPT ION QT Y COMMENT S
1 P12850 4.0m WOB MAIN FRAME PROACTIVE 1
2 AS1216 PROACTIVE TINE ASSEMBLY 13
3 P08198 WOB CULTIPRESS LIGHT MTG 2
4 P05797 LIGHT UNIT 2
5 P13033 HUB ASSEMBLY 6 STUD COMPLETE 2
6 P10029 SCRAPER 1 1/2 4
7 P05820 JUNCTION BOX 1
8 P00003 BOLT M12x40 GR. 8.8 34
9 P02037 WASHER SPRING M12 34
10 P02601 WASHER FLAT M12 34
11 P05796 REFLECTOR - RED 2
12 P05800 LIGHT PLATE 2
13 P02600 WASHER FLAT M10 8
14 P12690 BOLT M10x30 GR. 8.8 4
15 P06402 WASHER FLAT M4 4
16 P06401 NUT PLAIN M4 4
17 P06400 BOLT M4x15 GR. 8.8 4
18 P05534 NUT LOCK M10 4
19 P09112 CLAMP ½" BSP PAIR 3
20 P09113 CLAMP - TOP PLATE 3
21 P10278 BOLT M8x45 GR. 8.8 3
22 P07916 BUSH SPRUNG - Ø32xØ26x25 6
23 P01646 BUSH SPRUNG - Ø40xØ32x32 4
24 P00071 NIPPLE - GREASE 2
25 P09560 SCRAPER STEM LH 8
26 P02008 NUT LOCK M16 22
27 P02602 WASHER FLAT M16 22
28 P09558 SCRAPER PLATE 11
29 P06802 BOLT U M16 GR8.8 190x117 11
30 P09559 SCRAPER STEM RH 3
31 P05122 SERIAL PLATE 1
32 P13092 RIVET Ø3x10x Ø6 HEAD 4
33 P04128 WHEEL ASSY 400/60x15.5 6 STUD 2
34 P04412 RIM 400/60 - 6 STUD 1
35 P04413 TYRE 400/60-15.5 14PLY 1
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
