99 CultiPress
Operating Instructions
7. Parts & Assembly
AS1801 CU LT IPR ESS
4.0m W OB LEVELLIN G BOAR D ASSEMBLY
IT EM PART NO DESCRIPT ION QT Y COMMENT S
1 P00057 BOLT M16x60 GR. 8.8 4
2 P00071 NIPPLE - GREASE 2
3 P00407 BOLT M20x80 GR. 8.8 2
4 P01274 PIN Ø25x115 4
5 P01645 BUSH SPRUNG - Ø32xØ26x32 2
6 P01704 BOLT M16x50 GR8.8 34
7 P02008 NUT LOCK M16 38
8 P02009 NUT LOCK M20 6
9 P02010 NUT LOCK M24 2
10 P02483 LYNCH PIN CAT 1 2
11 P02484 LYNCH PIN CAT 2 4
12 P02602 WASHER FLAT M16 34
13 P02603 WASHER FLAT M20 4
14 P02604 WASHER FLAT M24 Ø50 2
15 P03115 BOLT M20x60 GR. 8.8 4
16 P07722 LEVELLING BOARD END PLATE 2
17 P08013 CYLINDER - Ø63x130 - 32 2
18 P09075 BOLT M24x125 GRS 2
19 P09201 LEVELLING BOARD ARM 2
20 P09202 TOP HAT BUSH 2
21 P09203 LEVELLING BOARD PIN 2
22 P09205 CULTIPRESS 2004 4.0m WOB LEVELING B 1
23 P09297 LEVELLING BOARD AXLE 6.6m 1
24 P00806 BOLT 7/16" UNFx40 34
25 P05749 EXTENSION PLATE V TYPE 17
26 P07220 UNF 7/16" PLAIN NUT 34
27 P07834 SPRUNG LEAF 17
