Great Plains Simba Culti Press 2009 Parts Manual - Manual (Page 21)

57 CultiPress
Operating Instructions
7. Parts & Assembly
AS1777 CU LT IPR ESS 2005
4.6m CH ASSIS ASSEMBLY PR OACT IVE
IT EM PART NO DESCRIPT ION QT Y COMMENT S
1 P13052 CULTIPRESS 2005 4.6m F/W CHASSIS 1
2 P07768 LIGHT MOUNTING BRACKET 2
3 P05797 LIGHT UNIT 2
4 P04233 SPANNER - M60 2
5 P05820 JUNCTION BOX 1
6 P00164 CYLINDER - Ø3¾"x400 - 45 4
7 P02484 LYNCH PIN CAT 2 12
8 P02759 CYLINDER - Ø3¾"x600 - 45 2
9 P13068 CULTIPRESS PARKING STAND 2005 2
10 P13033 HUB ASSEMBLY 6 STUD COMPLETE 2
11 P01645 BUSH SPRUNG - Ø32xØ26x32 7
12 P00378 BOLT M36x260 GR. 8.8 4
13 P01647 BUSH SPRUNG - Ø45xØ36x40 4
14 P00071 NIPPLE - GREASE 2
15 P05796 REFLECTOR - RED 2
16 P07544 PLASTIC END CAP 50x50 2
17 P02601 WASHER FLAT M12 4
18 P03090 BOLT M12x70 GR. 8.8 2
19 P02007 NUT LOCK M12 4
20 P09112 CLAMP ½" BSP PAIR 7
21 P09113 CLAMP - TOP PLATE 7
22 P02012 NUT LOCK M36 4
23 P02609 M36 FLAT WASHER 4
24 P01274 PIN Ø25x115 10
25 P07543 PLASTIC END CAP 40x40 2
26 P10278 BOLT M8x45 GR. 8.8 6
27 P01054 PIN Ø25x140 2
28 P03788 WHEEL ASSEMBLY - 500/50 2
29 P07979 WHEEL RIM 500/50 - 6 STUD 1
30 P09169 TYRE 500/50-15 1
31 P05122 SERIAL PLATE 1
32 P13092 RIVET Ø3x10x Ø6 HEAD 4
33 P07546 PLASTIC END CAP 80x80 2
34 P01281 BOLT M12x100 GR. 8.8 2
