53 CultiPress
Operating Instructions
7. Parts & Assembly
AS1799 CU LT IPR ESS 2005
3.3m W OB ASSEMBLY PR OACT IVE
IT EM PART NO DESCRIPT ION QT Y COMMENT S
1 P08198 WOB CULTIPRESS LIGHT MTG 2
2 P05797 LIGHT UNIT 2
3 AS1216 PROACTIVE TINE ASSEMBLY 11
4 P10029 SCRAPER 1 1/2 4
5 P05820 JUNCTION BOX 1
6 P00003 BOLT M12x40 GR. 8.8 28
7 P02037 WASHER SPRING M12 28
8 P02601 WASHER FLAT M12 28
9 P05800 LIGHT PLATE 2
10 P12690 BOLT M10x30 GR. 8.8 4
11 P02600 WASHER FLAT M10 8
12 P06401 NUT PLAIN M4 4
13 P06402 WASHER FLAT M4 4
14 P06400 BOLT M4x15 GR. 8.8 4
15 P05796 REFLECTOR - RED 2
16 P05534 NUT LOCK M10 4
17 P09112 CLAMP ½" BSP PAIR 3
18 P09113 CLAMP - TOP PLATE 3
19 P10278 BOLT M8x45 GR. 8.8 3
20 P07916 BUSH SPRUNG - Ø32xØ26x25 6
21 P01646 BUSH SPRUNG - Ø40xØ32x32 4
22 P00071 NIPPLE - GREASE 2
23 P09559 SCRAPER STEM RH 3
24 P06802 BOLT U M16 GR8.8 190x117 8
25 P02008 NUT LOCK M16 16
26 P02602 WASHER FLAT M16 16
27 P09558 SCRAPER PLATE 8
28 P09560 SCRAPER STEM LH 5
29 P05122 SERIAL PLATE 1
30 P13092 RIVET Ø3x10x Ø6 HEAD 4
31 P04233 SPANNER - M60 2
32 P07543 PLASTIC END CAP 40x40 2
33 P13033 HUB ASSEMBLY 6 STUD COMPLETE 2
34 P04128 WHEEL ASSY 400/60x15.5 6 STUD 2
35 P04412 RIM 400/60 - 6 STUD 1
36 P04413 TYRE 400/60-15.5 14PLY 1
37 P12988 CULTIPRESS 2004 3.3m WOB PROACTIVE 1
