Great Plains Simba Culti Press 2009 Parts Manual - Manual (Page 33)

69 CultiPress
Operating Instructions
7. Parts & Assembly
AS1779 CU LT IPR ESS 2005
4.6m R H W IN G ASSEMBLY PR OACT IVE
IT EM PART NO DESCRIPT ION QT Y COMMENT S
1 AS1216 PROACTIVE TINE ASSEMBLY 8
2 P00003 BOLT M12x40 GR. 8.8 16
3 P02008 NUT LOCK M16 'TYPE T' 8
4 P02009 NUT LOCK M20 2
5 P02037 WASHER SPRING M12 16
6 P02601 WASHER FLAT M12 16
7 P02602 WASHER FLAT M16 8
8 P02603 WASHER FLAT M20 7
9 P03115 BOLT M20x60 GR. 8.8 2
10 P05208 ROLL PIN ؼx1 5/8" 2
11 P06802 BOLT U M16 GR8.8 190x117 4
12 P07744 TIE STRAP SHORT 1
13 P07745 TIE STRAP - LONG 1
14 P07746 WING FOLD STRAP PIN 1
15 P07916 BUSH SPRUNG - Ø32xØ26x25 4
16 P09112 CLAMP ½" BSP PAIR 2
17 P09113 CLAMP - TOP PLATE 2
18 P09558 SCRAPER PLATE 4
19 P09559 SCRAPER STEM RH 4
20 P10029 SCRAPER 1 1/2 4
21 P10278 BOLT M8x45 GR. 8.8 2
22 P13059 WING UNIT RH 4.6m PRO ACTIVE 1
