Port locations – Great Plains Power Beyond User Manual
Page 16
ba01031
1 r4
page 4 of 10
Great Plains Manufacturing reserves the right to make changes or to add improvements to this guide at any time without notice or obligation.
PB 01/03/11
Port Locations
8030 Series
NOTE: Two possible power beyond pressure
and motor return port locations are shown.
8000R Series
NOTE: Two possible power beyond pressure
and motor return port locations are shown.
Load
Sense
Load
Sense
Motor
Return
Motor
Return
Case
Drain
Case
Drain
8000RT Series
8030T Series
Motor
Return
Case
Drain
Load
Sense
Motor
Return
Load
Sense
NOTE: Two possible power beyond pressure
and motor return port locations are shown.
Case
Drain
Power
Beyond
Pressure
Power
Beyond
Pressure
Power
Beyond
Pressure
Power
Beyond
Pressure
(limited access)
Power
Beyond
Pressure
Power
Beyond
Pressure
(limited access)
