9 Simba X-Press
601-338P
2013-09-20
Parts
Item Part No. Part Description Comments
1 601-001H CHASSIS - X-PRESS 3M
2 601-003H CHASSIS - X-PRESS 3.5M
3 601-060D ANGLE GUIDE
4 601-071H 4.0M X-PRESS CHASSIS
5 601-114H CHASSIS - X-PRESS 2.5M
6 601-118H TRACKROD FRONT 2.5M
601-048H TRACKROD FRONT 3.0M
601-120H TRACKROD FRONT 3.5M
601-122H TRACKROD FRONT 4.0M
7 601-119H TRACKROD REAR 2.5M
601-047H TRACKROD REAR 3.0M
601-121H TRACKROD REAR 3.5M
601-123H TRACKROD REAR 4.0M
8 601-147D ROLL LINKAGE BUSH
9 604-028D BAR DIA. 40MM
10 606-007H UPPER LINK PIN - CAT3
11 606-009H LOWER LINK PIN
12 606-069D LOWER LINK PIN
13 802-954C HHCS M6X1X30 GR8.8
14 803-354C NUT HEX M6-1
15 803-393C NUT HEX NYLOCK M20X2.5
16 803-412C NUT HEX M24X3 NYLON INSERT
17 804-160C WASHER FLAT M6 PLT
18 804-255C WASHER FLAT M24 - OD50MM
19 805-460C LYNCH PIN CAT 1
20 817-928C MANUAL HOLDER
21 842-031C HHCS M24X3X75 GR8.8
22 842-032C HHCS M20X2.5X70 GR8.8
23 891-301C ADJUSTER 350-600
Mainframe - Variable Angle (2.5m, 3.0m, 3.5m, 4.0m)
