46 Simba X-Press
601-338P
2013-09-20
Parts
BOLT TORQUES WHEEL NUT TORQUES
Bolt size Grade Kg.M lb.ft Nm Wheel Nuts Kg.M lb.ft Nm
M8 8.8 3 21.6 29.5 5/8" BSF 20.7 150 203
M10 8.8 5.9 42.6 58 M18 27.7 200 272
M12 8.8 10 72 98
10.9 135 TYRE PRESSURES
12.9
M16 8.8 24 174 235 Pressure
10.9 34 245 335 Tyre size Ply rating Psi Bar
12.9 18x19.5 16 70 4.5
M20 8.8 47 340 461 10/75-15 10 50 3.5
10.9 71 514 697 11.5/80-15 10 60 4
12.9 12.5/80-15 10 80 5.5
M24 8.8 80 579 785 400/60-15.5 10 50 3.5
10.9 110 795 1079 15/55-17 10 50 3.5
12.9 500/50-15.5 10 42 2.8
M30 8.8 150 1085 1471.5 500/50-17 10 35 2.4
10.9 500/50-17 14 50 3.5
12.9 20.0/70-20 12 50 3.5
M36 8.8 280 2025 2747 15.0x22.5 16 70 4.5
10.9 15/70-18 10 50 3.5
M39 8.8 700/50-22.5 12 35 2.4
10.9
M45 8.8
10.9
M60 8.8
10.9
3/4" UNF
1" UNF
1 3/4" BSW
5/8" UNC 24 174 235
Torque Torque
Standard Torques & Pressures
