Great Plains Simba X-Press Parts Manual - Manual (Page 3)

3 Simba X-Press
601-338P
2013-09-20
Parts
Contents (Alphabetical Order)
Aqueel II Roller ...............................................................................................................36
Cage, HD, V & ML Rollers ..............................................................................................32
DD Lite 550 Roller ..........................................................................................................34
Disc Arm Assembly (Single Hub) ....................................................................................22
Disc Arm Assembly (Twin Hub) ......................................................................................24
Disc Blades.....................................................................................................................28
Disc Hub Configurations .................................................................................................26
Hydraulic Circuit (4.0m FW) ...........................................................................................38
Light Kit - Front (2.5m, 3.0m, 3.5m, 4.0m)......................................................................40
Light Kit - Front (4.0m FW) .............................................................................................44
Light Kit - Rear (2.5m, 3.0m, 3.5m, 4.0m) ......................................................................42
Mainframe - 4.0m FW .....................................................................................................10
Mainframe - Fixed Angle (2.5m, 3.0m, 3.5m, 4.0m) .........................................................6
Mainframe - Variable Angle (2.5m, 3.0m, 3.5m, 4.0m) .....................................................8
Roll Frame - All Models ..................................................................................................20
Scraper Rail ....................................................................................................................30
Standard Torques & Pressures .......................................................................................46
Wing Frame LH - Fixed Angle - 4.0m FW.......................................................................12
Wing Frame LH - Variable Angle - 4.0m FW ..................................................................16
Wing Frame RH - Fixed Angle - 4.0m FW ......................................................................14
Wing Frame RH - Variable Angle - 4.0m FW ..................................................................18
