19 Simba X-Press
601-338P
2013-09-20
1 601-060D ANGLE GUIDE
2 601-097H DISC FRAME LH
3 601-126H PIN Ø30X115
4 601-127H TRACKROD XP - 8 HOLES 425MM
5 601-129H TRACKROD XP - 8 HOLES 300MM
6 601-147D ROLL LINKAGE BUSH
7 602-377D BOLT M39X200
8 604-028D BAR DIA. 40MM
9 803-393C NUT HEX NYLOCK M20X2.5
10 803-412C NUT HEX M24X3 NYLON INSERT
11 803-417C NUT SLOTTED M39X4
12 804-255C WASHER FLAT M24 - OD50MM
13 805-448C LYNCH PIN CAT 1
14 805-467C PIN SPLIT Ø5X75
15 842-031C HHCS M24X3X75 GR8.8
16 842-032C HHCS M20X2.5X70 GR8.8
17 891-301C DSGN START BLANK ASSY
Wing Frame RH - Variable Angle - 4.0m FW
Parts
Item Part No. Part Description Comments
