Great Plains Simba X-Press Parts Manual - Manual (Page 11)

11 Simba X-Press
601-338P
2013-09-20
Parts
Item Part No. Part Description Comments
1 601-014H CHASSIS X-PRESS 4M F/W
2 601-045H LIGHT BEAM
3 601-054H HEADSTOCK PLATE
4 601-124H PIN Ø30X93
5 601-125H LOWER LINK PIN CAT3
6 601-351D HEADSTOCK BRACE
7 601-390D BUSH Ø52XØ41X45
8 606-007H UPPER LINK PIN - CAT3
9 611-031H LIGHT MOUNT
10 611-156D HOSE STOWAGE PLATE
11 611-202D DECAL MOUNT - SPEED 90°
12 800-417C GREASE NIPPLE 1/8””BSP STRGHT
13 803-280C NUT HEX NYLOCK M10X1.5 PLT
14 803-281C NUT HEX NYLOCK M12X1.75 PLT
15 803-354C NUT HEX M6-1
16 803-386C NUT HEX NYLOCK M6X1
17 803-412C NUT HEX M24X3 NYLON INSERT
18 803-416C NUT HEX M30X3.5 NYLON INSERT
19 803-422C NUT HEX M8X2.00 NYLON INSERT
20 804-160C WASHER FLAT M6 PLT
21 804-161C WASHER FLAT M8 PLT
22 804-162C WASHER FLAT M10 PLT
23 804-246C WASHER FLAT M12 PLT
24 804-255C WASHER FLAT M24 - OD50MM
25 804-257C WASHER FLAT M30 - OD60MM PLT
26 805-448C LYNCH PIN CAT 1
27 805-460C LYNCH PIN CAT 1
28 806-239C U-BOLT M12X1.75 X 42 X 70
29 817-928C MANUAL HOLDER
30 833-602C FLASHING BEACON
31 833-608C LIGHT BOARD RRH
32 833-609C LIGHT BOARD RLH
33 842-023C HHCS M8X1.25X25 GR8.8 FTHD
34 842-029C HHCS M12X1.75X75 GR8.8
35 842-042C HHCS M10X1.5X40 GR8.8
36 842-043C HHCS M30X3.5X180 GR8.8
37 842-044C HHCS M30X3.5X90 GR8.8
38 842-045C HHCS M24X3X90 GR8.8
39 842-046C HHCS M6X1X55 GR8.8
40 842-075C HHCS M6X1X40 GR8.8
41 842-095C HSHCS M6X1X40 GR10.9
Mainframe - 4.0m FW
