12 8321-8552DV Great Plains Manufacturing, Inc.
550-353Q-ENG 02/12/2014
8321-8328, 8537-8544 Center Fold
Refer to Figure 7
18. Attach brace bar truss
(models 8537 & 8544) to
front of center brace bar, outside plates with 3/4 x 2
, 3/4 lock washers and 3/4 nuts, inside plates with
5/8 x 1 1/2 bolts , 5/8 lock washers and nuts.
19. Mount front and rear fold brackets to center
frame with 5/8 x 1 1/2 bolts , 5/8 lock washers and
nuts.
20. Attach inside plate of center wing stop , using 5/8 x
1 1/2 bolts , 5/8 lock washers and nuts.
21. Attach outside plate of center wing stop , with 5/8 x
3 1/32 x 5 1/2 u-bolts , 5/8 lock washers and nuts.
22. Insert the 1/2 x 4 1/2 pin w/keepers into round
tubes on rear of wing stop .
23. Mount cylinder rest pads , (Models 8321-8324
only) to center frame, with 1/2 x 3 1/32 x 5 u-bolts ,
1/2 lock washers and 1/2 nuts.
Note: Position cylinder rest pad 12” from inside of
outer tube to plate on pad as shown.
24. All bolts may be tightened to specs, See “Torque
Values Chart” on page 43.
1
2
5
3 4
5
6
5
6
7
8
6
9
10
9
