Great Plains TA520S Operator Manual User Manual
Page 44
1993-1995 Tandem Axle Sprayer
500-061M
3/18/2005
42
Nozzle
Size
Pressure
PSI
Gallons Per Acre At Miles Per Hour
4.00
5.00
6.00
7.00
8.00
9.00
10.00
11.00
12.00
10.0
10.00
49.50
39.60
33.00
28.29
24.75
22.00
19.80
18.00
16.50
15.00
60.39
48.31
40.26
34.51
30.20
26.84
24.16
21.96
20.13
20.00
69.80
55.84
46.53
39.88
34.90
31.02
27.92
25.38
23.27
25.00
77.72
62.17
51.81
44.41
38.86
34.54
31.09
28.26
25.91
30.00
85.64
68.51
57.09
48.93
42.82
38.06
34.25
31.14
28.55
35.00
91.58
73.26
61.05
52.33
45.79
40.70
36.63
33.30
30.53
40.00*
99.00
79.20
66.00
56.57
49.50
44.00
39.60
36.00
33.00
Nozzle
Size
Pressure
PSI
Gallons Per Acre At Miles Per Hour
4.00
5.00
6.00
7.00
8.00
9.00
10.00
11.00
12.00
12.5
10.00
61.88
49.50
41.25
35.36
30.94
27.50
24.75
22.50
20.63
15.00
75.74
60.59
50.49
43.28
37.87
33.66
30.29
27.54
25.25
20.00
87.62
70.09
58.41
50.07
43.81
38.94
35.05
31.86
29.21
25.00
98.01
78.41
65.34
56.01
49.01
43.56
39.20
35.64
32.67
30.00
107.91
86.33
71.94
61.66
53.96
47.96
43.16
39.24
35.97
35.00
114.35
91.48
76.23
65.34
57.17
50.82
45.74
41.58
38.12
40.00*
123.75
99.00
82.50
70.71
61.88
55.00
49.50
45.00
41.25
*For Post Emerge Applications where finer droplets are required use 40 PSI or greater.
Nozzle Size
Pressure
PSI
Gallons Per Acre At Miles Per Hour
4.00
5.00
6.00
7.00
8.00
9.00
10.00
11.00
12.00
15.0
10.00
74.25
59.40
49.50
42.43
37.13
33.00
29.70
27.00
24.75
15.00
91.08
72.86
60.72
52.05
45.54
40.48
36.43
33.12
30.36
20.00
104.94
83.95
69.96
59.97
52.47
46.64
41.98
38.16
34.98
25.00
117.32
93.85
78.21
67.04
58.66
52.14
46.93
42.66
39.11
30.00
128.70
102.96
85.80
73.54
64.35
57.20
51.48
46.80
42.90
35.00
137.61
110.09
91.74
78.63
68.81
61.16
55.04
50.04
45.87
40.00*
148.50
118.80
99.00
84.86
74.25
66.00
59.40
54.00
49.50
