MeterCone® Nozzles 30" Spacing -
Height 24" to 26" Angle Fixed 20˚
Nozzle Size
Pressure
PSI
Gallons Per Acre At Miles Per Hour
4.00
5.00
6.00
7.00
8.00
9.00
10.00
11.00
12.00
3.75
10.00
18.56
14.85
12.38
10.61
9.28
8.25
7.43
6.75
6.19
15.00
22.65
18.12
15.10
12.94
11.32
10.07
9.06
8.24
7.55
20.00
26.11
20.89
17.41
14.92
13.06
11.61
10.44
9.50
8.70
25.00
29.08
23.27
19.39
16.62
14.54
12.93
11.63
10.58
9.69
30.00
32.05
25.64
21.37
18.32
16.03
14.25
12.82
11.66
10.68
35.00
35.02
28.02
23.35
20.01
17.51
15.57
14.01
12.74
11.67
40.00*
37.00
29.60
24.67
21.14
18.50
16.45
14.80
13.46
12.33
45.00*
40.10
32.08
26.73
22.91
20.05
17.82
16.04
14.58
13.37
50.00*
42.57
34.06
28.38
24.33
21.29
18.92
17.03
15.48
14.19
55.00*
45.54
36.43
30.36
26.02
22.77
20.24
18.22
16.56
15.18
60.00*
48.51
38.81
32.34
27.72
24.26
21.56
19.40
17.64
16.17
*For Post Emerge Applications where finer droplets are required use 40 PSI or greater.
